ROTRON® Transportation
64 Frame Brushless DC Motors

Motor system for fans, blowers, pumps and compressors up to 1.25 hp. Its Electronically Commutated DC motor design provides long life up to 60,000 hours and offers maintenance-free operation by eliminating brush failures and repairs.
Features & Benefits
GO TO FEATURES & BENEFITS
Product Details
GO TO PRODUCT DETAILS
Markets & Applications
GO TO MARKETS & APPLICATIONS
Why Bison
GO TO WHY BISON

Features & Benefits

Benefit Card
Certification Icon

Buy America Compliant

Product meets Federal Regulation Title 49 CFR Part 661.
Benefit Card
Long Life Icon

Long Life

Electronically Commutated DC (ECDC™) motor series is built to last up to 60,000-hours.
Benefit Card
Protection Icon

Durable & Reliable

Rugged design withstands the harshest, most demanding operating environments.
Benefit Card
No Maintenance Icon

Maintenance Free

Brushless motor design eliminates brush failures and repairs. Decreases downtime.

Product Details

If the Product Detail content below is blank, please accept site cookies by clicking the green circle in the bottom-left corner of the page and selecting "Allow All".

  • Curve
  • Features & Options
  • Data Sheet
  • Case Studies

ROTRON Transportation 64 Frame Brushless DC Motor Performance Curve

Features
  • ECDC™ motor design
  • Rare-earth magnets provide high torque/weight ratio
  • Integral electronics provides simple two-wire
  • Wide range of voltage inputs of 12, 24, 37, and 74 VDC
  • O-ring sealed for harsh operating environments
  • Reverse polarity and voltage surge protected

Options
  • Custom shaft and mounting configurations (foot and face)
  • Winding variations to meet exact speed/torque/voltage point
  • Drop-in replacement motor design for existing brush motors
  • Available for OEM and retrofit applications
  • Complete blowers, fans, and pumps available

 Get more information about ROTRON Transportation 64 Frame Brushless DC Motors and how Bison can help with your next project.

ROTRON Transportation Data Sheet Image 400 x 300



Model Number Frame Size Fan Stages AC/DC Volt Motor Type Alt Parts
071075 4.6 N/A DC 27 64 Frame N/A
071139 4.6 N/A DC 27 64 Frame N/A
150101-00 4.6 N/A DC 36 64 Frame N/A
150101-01 4.6 N/A DC 36 64 Frame N/A
150172-00 4.6 N/A DC 24 64 Frame N/A
150214-00 4.6 N/A DC 27.6 64 Frame N/A
150215-00 4.6 N/A DC 27.6 64 Frame N/A
150215-02 4.6 N/A DC 27.6 64 Frame N/A
150355-00 4.6 N/A DC 27.6 64 Frame N/A
150355-01 4.6 N/A DC 27.6 64 Frame N/A
150355-02 4.6 N/A DC 27.6 64 Frame N/A
150386-00 4.6 N/A DC 37.5 64 Frame N/A
150912-00 4.6 N/A DC 37.5 64 Frame N/A
150921-00 4.6 N/A DC 48 64 Frame N/A
150975-00 4.6 N/A DC 27.6 64 Frame N/A
150976-00 4.6 N/A DC 28 64 Frame N/A
150976-01 4.6 N/A DC 28 64 Frame N/A
150976-02 4.6 N/A DC 28 64 Frame N/A
151005-00 4.6 N/A DC 37.5 64 Frame N/A
151140-00 4.6 N/A DC 27.6 64 Frame N/A
151187-01 4.6 N/A DC 27.6 64 Frame N/A
151208-00 4.6 N/A DC 27 64 Frame N/A
151255-00 4.6 N/A DC 24 64 Frame N/A
525835000 4.6 N/A DC 74 64 Frame N/A
