Find a productBison® 250 Series Parallel Shaft Gear Reducer
Shaft Input and NEMA 42C Flange Input, 142-295 in-lbs Torque
Specifications
Gearing: Hardened Steel, AGMA Class 9
Housing: Precision Machined Die Cast Aluminum
Lubrication: Lifetime Oil Bath, Sealed and Gasketed
Bearings: Ball, Needle and Thrust Ball
Shafts: Hardened Steel
Mounting: Face or Base, Any Angle
Input: Input Shaft or NEMA 42C
Specifications
Gearing: Hardened Steel, AGMA Class 9
Housing: Precision Machined Die Cast Aluminum
Lubrication: Lifetime Oil Bath, Sealed and Gasketed
Bearings: Ball, Needle and Thrust Ball
Shafts: Hardened Steel
Mounting: Face or Base, Any Angle
Input: Input Shaft or NEMA 42C
Features & Benefits
Made in the USA
Designed and manufactured in the United States.
Compact Design
Delivers optimal speed and torque in a small package. Perfect for applications that have limited space.
Customizable
Collaborate with Bison engineers to customize and seamlessly integrate the device into your end product, ensuring the perfect fit.
Durable & Reliable
Rugged design withstands the harshest, most demanding operating environments.
Product Details
If the Product Detail content below is blank, please accept site cookies by clicking the green circle in the bottom-left corner of the page and selecting "Allow All".
| Model Number | Description | Input Style |
Speed (RPM) |
Torque (in-lbs) |
OHL | Rated Input HP |
Gear Ratio |
|---|---|---|---|---|---|---|---|
| 030-255-0133 | Parallel Shaft Gear Reducer |
Shaft | 13 |
277 |
390 | 1/10 |
133.3 |
| 030-255-0013 | Parallel Shaft Gear Reducer |
Shaft | 136 |
142 |
170 |
1/3 |
12.7 |
| 030-256-0013 | Parallel Shaft Gear Reducer |
NEMA 42C |
136 |
142 |
170 |
1/3 |
12.7 |
| 030-255-0051 | Parallel Shaft Gear Reducer |
Shaft | 34 |
209 |
270 |
1/8 | 50.8 |
| 030-255-0036 | Parallel Shaft Gear Reducer |
Shaft | 48 |
295 |
210 |
1/4 |
35.8 |
| 030-255-0029 | Parallel Shaft Gear Reducer |
Shaft | 60 |
242 |
230 |
1/4 |
28.1 |
| 030-255-0019 | Parallel Shaft Gear Reducer |
Shaft | 90 |
275 |
190 |
1/3 |
19.1 |
Markets & Applications
Agricultural
Equipment
Equipment
Food & Beverage
Service
Service
Packaging
Equipment
Equipment
Energy
And So
Many More!
Many More!
Why Bison
Design Expertise, Customizable Solutions & Integration Support
Bison® engineers understand technical challenges and can provide customers so much more than an off-the-shelf part. We are a true technology partner – oftentimes becoming an extension of our customers’ design teams. We help solve problems as well as offer customizable solutions and integration support.
Engage with our engineers, locate an authorized distributor or connect with customer and technical support.
