Find a productLamb® 9" Bypass Tangential Vacuum Motors Flotek
Reach sealed vacuums up to 68" of H2O or flow rates up to 240 CFM. Lamb's highest flow product line specifically designed for material handling applications.
Features & Benefits
Specialized
Designed for material handling applications requiring high flow. Operating point optimized for maximum efficiency.
Highest Quality
Provides superior performance, durability and longevity, standing out in an industry inundated with subpar alternatives.
Extends Life
Incorporates durable construction that can withstand the wear and tear of constant use. Reduces repairs and replacements.
Customizable
Collaborate with Bison engineers to customize and seamlessly integrate the device into your end product, ensuring the perfect fit.
Product Details
If the Product Detail content below is blank, please accept site cookies by clicking the green circle in the bottom-left corner of the page and selecting "Allow All".
-
High Volt
-
Low Volt
-
Case Studies
| Features | |
|---|---|
| Models | Standard |
| Constructions | Diecast |
| Motor Designs | Comm Up |
| Discharges | Tangential Horn |
| Brushes | Cartridge |
| Fan Stages | 1 |
| Voltages | 120 or 240 |
| Performance | |
|---|---|
| Sealed Vacuum (In. of H20) | 68 |
| 7/8 Orifice Vacuum (In. of H20) | 55 |
| Open Airflow (CFM) | 240 |
| Peak Airwatts | 800 |
| Typical Operating Watts (7/8" Orifice) | 1718 |
| Features | |
|---|---|
| Models | Standard |
| Constructions | Diecast |
| Motor Designs | Comm Up |
| Discharges | Tangential Horn |
| Brushes | Cartridge |
| Fan Stages | 1 |
| Voltages | 24 or 36 |
| Performance | |
|---|---|
| Sealed Vacuum (In. of H20) | 25 - 29 |
| 7/8 Orifice Vacuum (In. of H20) | 18 - 23 |
| Open Airflow (CFM) | 140 - 156 |
| Peak Airwatts | 148 - 216 |
| Typical Operating Watts (7/8" Orifice) | 430 - 536 |
| Model Number | Frame Size | Fan Stages | AC/DC | Volt | Motor Type | Alt Parts |
|---|---|---|---|---|---|---|
| 119892-00 | 9 | 1 | AC | 120 | Flotek | N/A |
| 119892-04 | 9 | 1 | AC | 120 | Flotek | N/A |
| 119896-00 | 9 | 1 | AC | 230 | Flotek | N/A |
| 119896-04 | 9 | 1 | AC | 230 | Flotek | N/A |
| 119910-00 | 9 | 1 | DC | 36 | Flotek | N/A |
| 119910-07 | 9 | 1 | DC | 36 | Flotek | N/A |
| 119911-00 | 9 | 1 | DC | 24 | Flotek | N/A |
| 121118-00 | 9 | 1 | AC | 120 | Infinitek-Flotek | N/A |
| 121119-00 | 9 | 1 | AC | 230 | Infinitek-Flotek | N/A |
| 121131-00 | 9 | 1 | AC | 230 | Infinitek-Flotek | N/A |
| 121131-08 | 9 | 1 | AC | 230 | Infinitek-Flotek | N/A |
| 122379-00 | 9 | 1 | DC | 24 | Flotek | N/A |
| 122706-03 | 9 | 1 | DC | 36 | Flotek | N/A |
Markets & Applications
Providing the Highest Quality Vacuum Motors and Blowers For. . .
Material Handling Equipment
