Lamb® Thru-Flow Vacuum Motors - Advantek

Reach sealed vacuums up to 136" of H2O or flow rates up to 135 CFM. With the Advantek motor design, less input power is needed for the same air performance, leading to higher efficiency and longer life. These motors are typically more economical and weigh less than Lamb Comm Up Vacuum Motors.
Lamb Thru-Flow Advantek Vacuum Motors
Features & Benefits
GO TO FEATURES & BENEFITS
Product Details
GO TO PRODUCT DETAILS
Markets & Applications
GO TO MARKETS & APPLICATIONS
Why Bison
GO TO WHY BISON
Lamb Thru-Flow Advantek Vacuum Motors

Features & Benefits

Benefit Card
High Efficiency Icon

Advantek Motor

Reaches powerful air performance using less input power compared to other motors, leading to higher efficiency and longer life.

Benefit Card
Compact Design Icon

Compact Design

Delivers powerful suction while remaining lightweight and small. Ideal for designs that need a lot of vacuum with limited space.
Benefit Card
Long Life Icon

Extends Life

Incorporates durable construction that can withstand the wear and tear of constant use. Reduces repairs and replacements.
Benefit Card
Customization Icon

Customizable

Collaborate with Bison engineers to customize and seamlessly integrate the device into your end product, ensuring the perfect fit.

Product Details

If the Product Detail content below is blank, please accept site cookies by clicking the green circle in the bottom-left corner of the page and selecting "Allow All".

  • High Volt
  • Case Studies
Features
Models Standard or AirWatt Series
Constructions Steel Thermoset
Motor Designs Advantek/Comm Down
Discharges Thru-Flow
Brushes Carbon Straight or Eternity Curved
Fan Stages 1 or 2
Voltages 120 or 240
Performance
Sealed Vacuum (In. of H20) 63 - 136
7/8 Orifice Vacuum (In. of H20) 36 - 69
Open Airflow (CFM) 112 - 135
Peak Airwatts 255 - 650
Typical Operating Watts (7/8" Orifice 580 - 1540
Model Number Frame Size Fan Stages AC/DC Volt Motor Type Alt Parts
119720-00 5.1 1 AC 120 Advantek N/A
119874-00 4.3 1 AC 120 Advantek N/A
119890-00 4.3 1 AC 120 Advantek N/A
119928-00 4.2 1 AC 240 Advantek N/A
119995-00 5.7 1 AC 120 Advantek N/A
119996-00 5.7 1 AC 240 Advantek N/A
119997-00 5.7 2 AC 120 Advantek N/A
119997-07 5.7 2 AC 120 Advantek N/A
119997-08 5.7 2 AC 120 Advantek N/A
119997-41 5.7 2 AC 120 Advantek N/A
119998-07 5.7 2 AC 240 Advantek N/A
119998-08 5.7 2 AC 240 Advantek N/A
119998-41 5.7 2 AC 240 Advantek N/A
122041-00 5.7 1 AC 120 Advantek N/A
122042-00 5.7 2 AC 120 Advantek N/A
122043-00 5.7 2 AC 120 Advantek N/A
122044-00 5.7 1 AC 240 Advantek N/A
122045-00 5.7 2 AC 240 Advantek N/A
122046-00 5.7 2 AC 240 Advantek N/A
122058-01 4.3 1 AC 120 Advantek N/A
122064-00 5.1 1 AC 120 Advantek N/A
122093-00 5.7 2 AC 120 Advantek N/A
122094-00 4.8 1 AC 120 Advantek N/A
122111-00 5.7 1 AC 120 Advantek N/A
122132-00 5.1 1 AC 120 Advantek N/A
122141-00 4.8 1 AC 240 Advantek N/A
122147-08 5.7 2 AC 120 Advantek N/A
122167-00 4.8 1 AC 120 Advantek N/A
122167-07 4.8 1 AC 120 Advantek N/A
122251-00 5.7 1 AC 120 Advantek N/A
122264-00 5.7 2 AC 120 Advantek N/A
122264-07 5.7 2 AC 120 Advantek N/A
122264-08 5.7 2 AC 120 Advantek N/A
122264-46 5.7 2 AC 120 Advantek N/A
122286-07 5.7 2 AC 230 Advantek N/A
122286-08 5.7 2 AC 230 Advantek N/A
122286-41 5.7 2 AC 230 Advantek N/A
122286-46 5.7 2 AC 230 Advantek N/A
122287-07 5.7 2 AC 120 Advantek N/A
122287-08 5.7 2 AC 120 Advantek N/A
122287-25 5.7 2 AC 120 Advantek N/A
122288-00 5.7 2 AC 120 Advantek N/A
122288-08 5.7 2 AC 120 Advantek N/A
122288-41 5.7 2 AC 120 Advantek N/A
122289-07 5.7 2 AC 230 Advantek N/A
122289-08 5.7 2 AC 230 Advantek N/A
122294-00 5.7 2 AC 120 Advantek - curved brush N/A
122296-00 5.7 1 AC 120 Advantek N/A
122300-00 5.7 1 AC 120 Advantek - curved brush N/A
122310-00 5.7 1 AC 120 Advantek N/A
122314-00 5.7 1 AC 120 Advantek N/A
122321-00 5.7 2 AC 230 Advantek - curved brush N/A
122321-01 5.7 2 AC 230 Advantek - curved brush N/A
122321-02 5.7 2 AC 230 Advantek - curved brush N/A
122321-05 5.7 2 AC 230 Advantek - curved brush N/A
122323-00 5.7 2 AC 120 Advantek - curved brush N/A
122323-08 5.7 2 AC 120 Advantek - curved brush N/A
122342-00 5.7 1 AC 120 Advantek N/A
122343-00 5.7 1 AC 240 Advantek N/A
122348-07 5.4 1 AC 120 Advantek N/A
122392-00 5.7 2 AC 120 Advantek N/A
122420-00 4.2 1 DC 36 Advantek N/A
122445-00 5.7 2 AC 120 Advantek - curved brush N/A
122454-00 5.7 1 AC 120 Advantek - curved brush N/A
122476-07 5.4 1 AC 120 Advantek N/A
122512-00 5.7 1 AC 120 Advantek N/A
122527-00 5.7 1 AC 240 5.7 Advantek III N/A
122528-00 5.7 1 AC 120 5.7 Advantek III N/A
122541-01 4.3 1 AC 120 Advantek N/A
122543-00 5.1 1 AC 120 Advantek N/A
122544-00 5.1 1 AC 120 Advantek N/A
122544-08 5.1 1 AC 120 Advantek N/A
122545-00 5.1 1 AC 240 Advantek N/A
122546-00 5.1 1 AC 240 Advantek N/A
122546-08 5.1 1 AC 240 Advantek N/A
122604-00 4.8 1 AC 120 4.8 Advantek N/A
122608-00 4.8 1 AC 120 4.8 Advantek N/A
122659-00 5.7 1 AC 120 5.7 Advantek III N/A
122683-07 5.7 2 AC 120 Advantek N/A

Markets & Applications

Providing the Highest Quality Vacuum Motors and Blowers For. . .

Animal Grooming Vacuum Motors
Animal Grooming Equipment
Carpet Scrubbers Vacuum Motors
Carpet Extractors / Scrubbers
Central Vac Vacuum
Central
Vacuums
Industrial Vacuum Vacuum Motors
Industrial
Vacuums
Material Handling Icon
Material Handling Equipment
And So Much More Icon
And So
Many More!

Why Bison

Design Expertise, Customizable Solutions & Integration Support


Bison® engineers understand technical challenges and can provide customers so much more than an off-the-shelf part. We are a true technology partner – oftentimes becoming an extension of our customers’ design teams. We help solve problems as well as offer customizable solutions and integration support.
