Lamb® 5.7" Bypass Tangential Vacuum Motors

Reach sealed vacuums up to 220" of H2O or flow rates up to 107 CFM. The options include either diecast or thermoset horn discharges. Both are ideal for guiding pressurized air and optimizing these motors for a variety of vacuum- and pressure-based applications.
Lamb 57 Bypass Tangential Vacuum Motors
Features & Benefits
GO TO FEATURES & BENEFITS
Product Details
GO TO PRODUCT DETAILS
Markets & Applications
GO TO MARKETS & APPLICATIONS
Why Bison
GO TO WHY BISON
Lamb 57 Bypass Tangential Vacuum Motors

Features & Benefits

Benefit Card
Compact Design Icon

Compact Design

Delivers powerful suction while remaining lightweight and small. Ideal for designs that need a lot of vacuum with limited space.
Benefit Card
Best Icon

Highest Quality

Provides superior performance, durability and longevity, standing out in an industry inundated with subpar alternatives.
Benefit Card
Tangential Horn Discharge Icon

Horn Discharge

Directs airflow effectively, rendering these motors optimal for a diverse range of vacuum and pressure applications.
Benefit Card
Customization Icon

Customizable

Collaborate with Bison engineers to customize and seamlessly integrate the device into your end product, ensuring the perfect fit.

Product Details

If the Product Detail content below is blank, please accept site cookies by clicking the green circle in the bottom-left corner of the page and selecting "Allow All".

  • High Volt
  • Low Volt
  • Case Studies
Features
Models Standard, AirWatt Series and HVLP
Constructions Diecast or Thermoset
Motor Designs Comm Up
Discharges Tangential Horn
Brushes Cartridge or Carbon Only
Fan Stages 1 - 6
Voltages 120 or 240
Performance
Sealed Vacuum (In. of H20) 45 - 220
7/8 Orifice Vacuum (In. of H20) 30 - 63
Open Airflow (CFM) 90 - 107
Peak Airwatts 150 - 620
Typical Operating Watts (7/8" Orifice) 640 - 1800
Features
Models Standard
Constructions Diecast or Thermoset
Motor Designs Comm Up
Discharges Tangential Horn
Brushes Cartridge
Fan Stages 1 - 3
Voltages 24 or 36
Performance
Sealed Vacuum (In. of H20) 50 - 70
7/8 Orifice Vacuum (In. of H20) 18 - 30
Open Airflow (CFM) 65 - 80
Peak Airwatts 100 - 180
Typical Operating Watts (7/8" Orifice) 380 - 670
Model Number Frame Size Fan Stages AC/DC Volt Motor Type Alt Parts
115894 5.7 2 AC 120 Traditional Lamb N/A
115909 5.7 2 AC 120 Traditional Lamb N/A
115961 5.7 2 AC 240 Traditional Lamb N/A
116077-13 5.7 2 AC 220 Traditional Lamb N/A
116114-00 5.7 2 AC 120 Traditional Lamb N/A
116116-00 5.7 2 AC 120 Traditional Lamb N/A
116157-00 5.7 2 DC 24 Traditional Lamb N/A
116157-18 5.7 2 DC 24 Traditional Lamb N/A
116157-21 5.7 2 DC 24 Traditional Lamb N/A
116157-29 5.7 2 DC 24 Traditional Lamb N/A
116157-32 5.7 2 DC 24 Traditional Lamb N/A
116157-38 5.7 2 DC 24 Traditional Lamb N/A
116158-00 5.7 2 DC 36 Traditional Lamb N/A
116158-01 5.7 2 DC 36 Traditional Lamb N/A
116181-00 5.7 2 AC 120 Traditional Lamb N/A
116207-00 5.7 2 AC 120 Traditional Lamb N/A
116210-50 5.7 2 AC 120 Traditional Lamb N/A
116210-85 5.7 2 AC 120 Traditional Lamb N/A
116213-00 5.7 2 AC 240 Traditional Lamb N/A
116259-00 5.7 2 AC 240 Traditional Lamb N/A
116259-11 5.7 2 AC 240 Traditional Lamb N/A
116266-00 5.7 1 AC 240 Traditional Lamb N/A
116353-00 5.7 2 AC 220 Traditional Lamb N/A
116353-13 5.7 2 AC 220 Traditional Lamb N/A
116355-00 5.7 2 AC 240 Traditional Lamb N/A
116355-01 5.7 2 AC 240 Traditional Lamb N/A
116355-29 5.7 2 AC 240 Traditional Lamb N/A
116359-00 5.7 1 AC 220 Traditional Lamb N/A
116392-00 5.7 2 AC 120 Traditional Lamb N/A
116392-01 5.7 2 AC 120 Traditional Lamb N/A
116392-03 5.7 2 AC 120 Traditional Lamb N/A
116392-29 5.7 2 AC 120 Traditional Lamb N/A
116392-32 5.7 2 AC 120 Traditional Lamb N/A
116392-42 5.7 2 AC 120 Traditional Lamb N/A
116409-13 5.7 2 DC 36 Traditional Lamb N/A
116409-29 5.7 2 DC 36 Traditional Lamb N/A
116414-13 5.7 2 AC 240 Traditional Lamb N/A
116414-29 5.7 2 AC 240 Traditional Lamb N/A
116420-13 5.7 2 AC 240 Traditional Lamb N/A
116472-00 5.7 2 AC 120 Traditional Lamb N/A
116472-13 5.7 2 AC 120 Traditional Lamb N/A
116472-18 5.7 2 AC 120 Traditional Lamb N/A
116472-29 5.7 2 AC 120 Traditional Lamb N/A
116472-39 5.7 2 AC 120 Traditional Lamb N/A
116474-00 5.7 2 AC 120 Traditional Lamb N/A
116474-37 5.7 2 AC 120 Traditional Lamb N/A
116513-07 5.7 3 DC 36 Traditional Lamb N/A
116513-08 5.7 3 DC 36 Traditional Lamb N/A
116513-13 5.7 3 DC 36 Traditional Lamb N/A
116513-18 5.7 3 DC 36 Traditional Lamb N/A
116513-24 5.7 3 DC 36 Traditional Lamb N/A
116513-29 5.7 3 DC 36 Traditional Lamb N/A
116513-32 5.7 3 DC 36 Traditional Lamb N/A
116515-06 5.7 3 DC 24 Traditional Lamb N/A
116515-07 5.7 3 DC 24 Traditional Lamb N/A
116515-13 5.7 3 DC 24 Traditional Lamb N/A
116515-18 5.7 3 DC 24 Traditional Lamb N/A
116515-24 5.7 3 DC 24 Traditional Lamb N/A
116515-29 5.7 3 DC 24 Traditional Lamb N/A
116515-32 5.7 3 DC 24 Traditional Lamb N/A
116515-40 5.7 3 DC 24 Traditional Lamb N/A
116515-48 5.7 3 DC 24 Traditional Lamb N/A
116520-50 5.7 1 AC 120 Traditional Lamb N/A
116565-00 5.7 3 AC 120 Traditional Lamb N/A
116565-13 5.7 3 AC 120 Traditional Lamb N/A
116565-29 5.7 3 AC 120 Traditional Lamb N/A
116594-13 5.7 2 AC 220 Traditional Lamb N/A
116657-00 5.7 2 AC 240 Traditional Lamb N/A
116657-37 5.7 2 AC 240 Traditional Lamb N/A
116698-13 5.7 3 AC 120 Traditional Lamb N/A
116700-00 5.7 2 AC 120 Traditional Lamb N/A
116753-13 5.7 3 AC 100 Traditional Lamb N/A
116754-13 5.7 2 AC 120 Traditional Lamb N/A
116765-00 5.7 3 AC 120 Traditional Lamb N/A
116765-13 5.7 3 AC 120 Traditional Lamb N/A
116765-18 5.7 3 AC 120 Traditional Lamb N/A
116765-20 5.7 3 AC 120 Traditional Lamb N/A
116765-29 5.7 3 AC 120 Traditional Lamb N/A
116765-48 5.7 3 AC 120 Traditional Lamb N/A
116859-00 5.7 3 AC 240 Traditional Lamb N/A
116859-13 5.7 3 AC 240 Traditional Lamb N/A
116859-29 5.7 3 AC 240 Traditional Lamb N/A
116905-13 5.7 2 AC 120 Traditional Lamb N/A
117073-00 5.7 2 AC 120 Traditional Lamb N/A
117073-37 5.7 2 AC 120 Traditional Lamb N/A
117073-45 5.7 2 AC 120 Traditional Lamb N/A
117123-00 5.7 3 AC 240 Traditional Lamb N/A
117123-07 5.7 3 AC 240 Traditional Lamb N/A
117123-11 5.7 3 AC 240 Traditional Lamb N/A
117123-13 5.7 3 AC 240 Traditional Lamb N/A
117123-29 5.7 3 AC 240 Traditional Lamb N/A
117123-35 5.7 3 AC 240 Traditional Lamb N/A
117123-45 5.7 3 AC 240 Traditional Lamb N/A
117148-13 5.7 2 AC 240 Traditional Lamb N/A
117160-13 5.7 2 AC 100 Traditional Lamb N/A
117196-00 5.7 3 AC 240 Traditional Lamb N/A
117196-13 5.7 3 AC 240 Traditional Lamb N/A
117246-00 5.7 4 AC 230 HVLP PressureSprayer N/A
117275-00 5.7 2 AC 230 Traditional Lamb N/A
117275-11 5.7 2 AC 230 Traditional Lamb N/A
117395-37 5.7 1 AC 120 Traditional Lamb N/A
117403-00 5.7 1 AC 240 Traditional Lamb N/A
117403-13 5.7 1 AC 240 Traditional Lamb N/A
117403-37 5.7 1 AC 240 Traditional Lamb N/A
117446-29 5.7 3 AC 120 Traditional Lamb N/A
117447-29 5.7 3 AC 240 Traditional Lamb N/A
117795-00 5.7 2 AC 120 Traditional Lamb N/A
117795-01 5.7 2 AC 120 Traditional Lamb N/A
117795-07 5.7 2 AC 120 Traditional Lamb N/A
117796-00 5.7 2 AC 240 Traditional Lamb N/A
117796-07 5.7 2 AC 240 Traditional Lamb N/A
119207-13 5.7 2 AC 240 Traditional Lamb N/A
119241-13 5.7 2 AC 240 Traditional Lamb N/A
119260-07 5.7 2 AC 120 Traditional Lamb N/A
119292-00 5.7 4 AC 120 HVLP PressureSprayer N/A
119336-50 5.7 1 AC 120 Traditional Lamb N/A
119407-00 5.7 2 AC 120 Economy N/A
119407-13 5.7 2 AC 120 Economy N/A
119410-00 5.7 2 AC 120 Economy N/A
119410-37 5.7 2 AC 120 Traditional Lamb N/A
119412-00 5.7 2 AC 120 Economy N/A
119412-08 5.7 2 AC 120 Economy N/A
119412-13 5.7 2 AC 120 Economy N/A
119432-13 5.7 3 DC 36 LVDC N/A
119432-24 5.7 3 DC 36 LVDC N/A
119432-29 5.7 3 DC 36 LVDC N/A
119432-46 5.7 3 DC 36 LVDC N/A
119432-53 5.7 3 AC 36 Traditional Lamb N/A
119433-07 5.7 3 DC 24 Economy N/A
119433-13 5.7 3 DC 24 Economy N/A
119433-14 5.7 3 DC 24 Economy N/A
119433-29 5.7 3 DC 24 Economy N/A
119433-32 5.7 3 DC 24 Economy N/A
119434-13 5.7 2 DC 36 Economy N/A
119436-06 5.7 2 DC 24 Economy N/A
119436-07 5.7 2 DC 24 Economy N/A
119436-13 5.7 2 DC 24 Economy N/A
119436-14 5.7 2 DC 24 Economy N/A
119436-29 5.7 2 DC 24 Economy N/A
119512-00 5.7 1 AC 120 Traditional Lamb N/A
119520-29 5.7 2 DC 36 Economy N/A
119549-00 5.7 3 AC 230 Traditional Lamb N/A
119561-00 5.7 1 AC 230 AirWattSeries N/A
119625-00 5.7 2 AC 240 Traditional Lamb N/A
119631-00 5.7 2 AC 120 AirWattSeries N/A
119632-07 5.7 2 AC 120 Economy N/A
119633-07 5.7 2 AC 120 AirWattSeries N/A
119678-00 5.7 2 AC 240 AirWattSeries N/A
119678-07 5.7 2 AC 240 AirWattSeries N/A
119678-11 5.7 2 AC 240 AirWattSeries N/A
119679-07 5.7 2 AC 240 Traditional Lamb N/A
119692-00 5.7 2 AC 240 Traditional Lamb N/A
119703-29 5.7 2 DC 24 Traditional Lamb N/A
119708-00 5.7 2 AC 120 AirWattSeries N/A
119709-00 5.7 2 AC 240 AirWattSeries N/A
119710-00 5.7 2 AC 230 AirWattSeries N/A
119711-00 5.7 2 AC 230 AirWattSeries N/A
119731-18 5.7 2 DC 24 Economy N/A
119736-37 5.7 1 AC 120 Traditional Lamb N/A
119785-07 5.7 2 AC 120 AirWattSeries N/A
119787-07 5.7 2 AC 240 AirWattSeries N/A
119797-19 5.7 3 AC 120 Traditional Lamb N/A
119799-19 5.7 3 AC 240 Traditional Lamb N/A
119885-13 5.7 3 AC 120 Traditional Lamb N/A
119891-06 5.7 2 DC 24 Economy N/A
119891-29 5.7 2 DC 24 Economy N/A
119913-07 5.7 2 AC 120 AirWattSeries N/A
119914-07 5.7 2 AC 120 AirWattSeries N/A
119914-45 5.7 2 AC 120 AirWattSeries N/A
119914-48 5.7 2 AC 120 AirWattSeries N/A
119915-07 5.7 2 AC 120 AirWattSeries N/A
119956-00 5.7 2 AC 120 AirWattSeries N/A
119992-00 5.7 2 AC 115 AirWattSeries N/A
122033-00 5.7 2 AC 115 AirWattSeries N/A
122039-00 5.7 2 AC 240 AirWattSeries N/A
122049-00 5.7 4 AC 120 HVLP PressureSprayer N/A
122050-00 5.7 5 AC 120 HVLP PressureSprayer N/A
122050-07 5.7 5 AC 120 HVLP PressureSprayer N/A
122059-07 5.7 2 AC 230 AirWattSeries N/A
122059-25 5.7 2 AC 230 AirWattSeries N/A
122060-25 5.7 2 AC 230 AirWattSeries N/A
122061-07 5.7 2 AC 230 AirWattSeries N/A
122097-00 5.7 6 AC 120 HVLP PressureSprayer N/A
122101-07 5.7 2 AC 240 AirWattSeries N/A
122113-13 5.7 3 AC 240 Traditional Lamb N/A
122117-40 5.7 3 DC 24 Traditional Lamb N/A
122146-00 5.7 5 AC 230 HVLP PressureSprayer N/A
122159-07 5.7 2 AC 120 Traditional Lamb N/A
122163-00 5.7 3 AC 240 Traditional Lamb N/A
122189-00 5.7 4 AC 230 HVLP PressureSprayer N/A
122195-00 5.7 4 AC 120 HVLP PressureSprayer N/A
122196-00 5.7 4 AC 240 HVLP PressureSprayer N/A
122220-00 5.7 5 AC 120 HVLP PressureSprayer N/A
122221-00 5.7 4 AC 120 HVLP PressureSprayer N/A
122222-00 5.7 3 AC 120 HVLP PressureSprayer N/A
122228-01 5.7 2 AC 120 Traditional Lamb N/A
122304-00 5.7 2 AC 120 AIR MOVING N/A
122373-00 5.7 3 AC 120 Traditional Lamb N/A
122375-00 5.7 2 AC 120 Traditional Lamb N/A
122376-00 5.7 2 AC 240 Traditional Lamb N/A
122402-00 5.7 2 AC 240 Traditional Lamb N/A
122438-45 5.7 3 AC 120 Traditional Lamb N/A
122439-45 5.7 3 AC 120 Traditional Lamb N/A
122448-45 5.7 3 AC 120 Traditional Lamb N/A
122469-07 5.7 2 AC 120 5.7 Air Moving N/A
122471-25 5.7 2 AC 120 5.7 Air Moving N/A
122482-00 5.7 5 AC 120 HVLP PressureSprayer N/A
122492-06 5.7 2 DC 24 Economy N/A
122497-07 5.7 3 DC 24 Traditional Lamb N/A
122497-29 5.7 3 DC 24 Traditional Lamb N/A
122509-00 5.7 5 AC 230 HVLP PressureSprayer N/A
122509-07 5.7 5 AC 230 HVLP PressureSprayer N/A
122511-40 5.7 3 AC 240 Traditional Lamb N/A
122525-00 5.7 2 AC 120 Air Moving N/A
122557-00 5.7 2 AC 240 Traditional Lamb N/A
122558-00 5.7 2 DC 24 Traditional Lamb N/A
122561-00 5.7 3 AC 120 Traditional Lamb N/A
122565-29 5.7 3 AC 120 Traditional Lamb N/A
122568-00 5.7 3 AC 240 Traditional Lamb N/A
122617-00 5.7 5 AC 230 HVLP PressureSprayer N/A
122626-43 5.7 3 DC 36 Traditional Lamb N/A
122626-44 5.7 3 DC 36 Traditional Lamb N/A
122678-00 5.7 1 AC 120 Traditional Lamb N/A
122685-00 5.7 2 AC 120 Traditional Lamb N/A
122685-07 5.7 2 AC 120 Traditional Lamb N/A
122685-27 5.7 2 AC 120 Traditional Lamb N/A
122727-29 5.7 3 DC 24 Traditional Lamb N/A
122732-00 5.7 3 AC 120 Traditional Lamb N/A
122733-40 5.7 3 AC 240 Traditional Lamb N/A
122758-00 5.7 2 AC 120 Traditional Lamb N/A
130805-13 5.7 2 DC 24 Traditional Lamb N/A

Markets & Applications

Providing the Highest Quality Vacuum Motors and Blowers For. . .

Boat Lifts
Boat
Lifts
Carpet Scrubbers Vacuum Motors
Carpet Extractors / Scrubbers
Central Vac Vacuum
Central
Vacuums
Dock Loaders Icon
Dock
Loaders
Sprayer Icon
Sprayers and
Foggers
And So Much More Icon
And So
Many More!

Why Bison

Design Expertise, Customizable Solutions & Integration Support


Bison® engineers understand technical challenges and can provide customers so much more than an off-the-shelf part. We are a true technology partner – oftentimes becoming an extension of our customers’ design teams. We help solve problems as well as offer customizable solutions and integration support.



Read More
bison contact form icon
Engage with our engineers, locate an authorized distributor or connect with customer and technical support.
Contact Bison
